| ชื่อแบรนด์: | GQZ |
| หมายเลขรุ่น: | XR820060 |
| ปริมาณการสั่งซื้อขั้นต่ำ: | 5 ชิ้น |
| ราคา: | $1709-$1729 |
| เวลาการส่งมอบ: | 3 วันทำการหลังจากได้รับการชำระเงินของคุณ |
| เงื่อนไขการชำระเงิน: | T/T หรือ Western Union หรือ Paypal |
The XR820060 Cross Tapered Roller Bearing is a super large, heavy-duty precision bearing designed for mobile robot parts, CNC systems, and industrial equipment. With dimensions of 580mm inner diameter, 760mm outer diameter, and 80mm width, it provides exceptional rigidity, high load capacity, and stable rotational performance.
Engineered for extreme working conditions, this bearing ensures reliable motion control, high torque transmission, and long service life in mobile robotics and heavy-duty machinery applications.
| Parameter | XR820060 |
|---|---|
| Model | XR820060 |
| Inner Diameter (ID) | 580 mm |
| Outer Diameter (OD) | 760 mm |
| Width (H) | 80 mm |
| Type | Cross Tapered Roller Bearing |
| Structure | Crossed Tapered Rollers |
| Material | Bearing Steel |
| Preload | Custom |
| Accuracy Class | P5 / P4 optional |
| Application | Mobile Robots, CNC Machines, Heavy Equipment |
| Timken | KG | d | D | B | r | Cr (KN) | Co (KN) | Cr (KN) | ||
|---|---|---|---|---|---|---|---|---|---|---|
| - | 4.9 | 150 | 230 | 30 | 1 | 95.2 | 156 | 111 | 279 | 1100 |
| - | 5.15 | 160 | 240 | 30 | 1.1 | 96.8 | 162 | 118 | 300 | 1000 |
| - | 6.7 | 200 | 280 | 30 | 1.5 | 102 | 175 | 120 | 320 | 9000 |
| XR496051 | 5.59 | 203.2 | 279.4 | 31.75 | 1.5 | 110 | 188 | 134 | 348 | 850 |
| XR496052 | 5.59 | 203.2 | 279.4 | 31.75 | 1.5 | 110 | 188 | 134 | 348 | 850 |
| - | 5.4 | 240 | 300 | 30 | 1 | 88 | 184 | 114 | 361 | 750 |
| - | 4.5 | 250 | 310 | 25 | 1 | 88 | 188 | 114 | 361 | 700 |
| - | 13 | 250 | 350 | 40 | 1.3 | 187 | 355 | 228 | 657 | 670 |
| JXR637050 | 12.5 | 300 | 400 | 36.492 | 1.5 | 183 | 355 | 223 | 657 | 560 |
| JXR637050 | 12.5 | 300 | 400 | 37 | 1.5 | 183 | 355 | 223 | 657 | 560 |
| JXR678054 | 38 | 300 | 480 | 60 | 1.5 | 258 | 495 | 35 | 920 | 600 |
| JXR652050 | 19.5 | 310 | 425 | 45 | 2.5 | 216 | 427 | 281 | 837 | 640 |
| JXR678052 | 32 | 330.2 | 457.2 | 63.5 | 3.3 | 264 | 515 | 312 | 954 | 620 |
| - | 27 | 350 | 470 | 50 | 3.3 | 308 | 635 | 376 | 1180 | 560 |
| JXR699050 | 30 | 370 | 495 | 50 | 3.3 | 93.6 | - | 119 | - | 600 |
| - | 15 | 400 | 480 | 40 | 1.1 | 216 | 497 | 281 | 957 | 430 |
| - | 46.5 | 400 | 550 | 60 | 2.5 | 429 | 920 | 523 | 1700 | 400 |
| XR736052 | 27.5 | 432.003 | 571.5 | 38.1 | 3.3 | 83 | 910 | 530 | 1600 | 400 |
| JXR766051 | 51 | 457.2 | 609.6 | 63.5 | 3.3 | 396 | 856 | 514 | 1680 | 420 |
| JXR766052 | 62 | 424.95 | 614.924 | 65 | 3.3 | 470 | 960 | 600 | 1720 | 380 |
| JXR820060 | 100 | 580 | 760 | 80 | 3.3 | 627 | 1380 | 765 | 2560 | 300 |
| JXR820061 | 100 | 580 | 760 | 80 | 6.4 | 627 | 1380 | 765 | 2560 | 300 |
| JXR836050 | 148 | 600 | 830 | 80 | 6.4 | 680 | 1460 | 820 | 2870 | 300 |
| JXR8444050 | 150 | 685.8 | 914.4 | 79.375 | 6.4 | 693 | 1660 | 900 | 3250 | 260 |
| JXR855053 | 150 | 685.8 | 914.4 | 79.375 | 3.3 | 693 | 1660 | 900 | 3250 | 260 |
| JXR855056 | 150 | 685.8 | 914.4 | 79.375 | 3.3 | 693 | 1660 | 900 | 3250 | 260 |
| JXR882054 | 185 | 901.7 | 1117.6 | 82.555 | 3 | 781 | 2060 | 1060 | 4290 | 200 |
| JXR882055 | 185 | 901.7 | 1117.6 | 82.555 | 3.3 | 781 | 2060 | 1060 | 4290 | 200 |
| JXR882058 | 158 | 939.8 | 1117.6 | 82.55 | 3 | 920 | 2580 | 1200 | 5000 | 200 |
| - | 215 | 950 | 1170 | 85 | 3 | 968 | 2690 | 1310 | 5600 | 215 |
| JXR889058 | 430 | 1028.7 | 1327.15 | 114.3 | 3.3 | 1230 | 3310 | 1600 | 6490 | 430 |
| JXR889059 | 358 | 1028.7 | 1327.15 | 95.25 | 3.3 | 1060 | 3100 | 1420 | 6020 | 450 |
| JXR889060 | 430 | 1028.7 | 1327.15 | 114.3 | 3.3 | 1230 | 3310 | 1600 | 6490 | 430 |
| - | 350 | 1270 | 1524 | 95.25 | 3.3 | 1300 | 3830 | 1760 | 2980 | 95 |
| JXR897051 | 500 | 1549.4 | 1828.8 | 101.6 | 3.3 | 1400 | 4510 | 1890 | 9400 | 80 |
| - | 675 | 1879.6 | 2197.1 | 101.6 | 5.4 | 1510 | 5240 | 2040 | 10900 | 43 |
| - | 1130 | 2463.8 | 2819.4 | 114.3 | 5.4 | 2330 | 8740 | 3150 | 18200 | 18200 |
A1: Yes, it is designed for high-load and precision motion systems in mobile robotics.
A2: Yes, it is engineered for large-scale and high-load industrial applications.
A3: Yes, we support customization for preload, precision grade, and materials.
Power your system with XR820060 Cross Tapered Roller Bearing.
Contact GQZ Bearing today for pricing, samples, or technical consultation!
